? Three zones and a separate key-switch input
? Three user codes and an unlock door code
? Quick Arm function
? Built-in piezo buzzer
? Built-in tamper switch
? Keys back-lit by LEDs

The DS3MX is a three-zone mini panel which can be
installed as a stand-alone device or connected to the
DS7400Xi Control/Communicator's Multiplex Bus for
integrating individual apartment housing units into a large
building monitoring system. The DS3MX is capable of
sending Arm, Disarm, Alarm, Tamper, and Trouble
information to the DS7400Xi. Additionally this information
can be reported from the DS7400Xi to the CMS7000 multipanel
monitoring software. (Refer to CMS7000 documents
for more information.)
Note Use with DS7400Xi requires DS7400Xi-CHI
with ROM version 4.05 or later.
The mini panel has three alarm input zones, one alarm relay
output, two solid-state outputs, key switch input, instant
input and supports three user PIN codes including the
master code and one door unlock PIN code.
